EXPERIMENTAL FACILITIES

• theta-2theta vertical
• Cu X-ray tube
• Point focus optics, X-ray lens - polycapillary
• Large Eulerian cradle
• low-resolution optics, Goebel parabolic mirror, parallel plate collimator
• high-resolution optics, Goebel parabolic mirror, Barthels four-crystal monochromator, crystal analyzer
• full PC control

Komentáře

• theta-2theta goniometer
• automatic alignment
• Cu X-ray tube
• thin film parallel beam attachment with
  a curved diffracted beam graphite monochromator
• software XDAL/APX

Komentáře

• Seemann-Bohlin goniometer
• Philips PW 1830 X-ray generator
• Ge primary beam monochromator, graphite diffracted beam monochromator
• texture attachment
• high-temperature chamber (up to 900^oC)
• measurement and control system running on a PC

• Chirana X-ray generators
• cameras for Laue, Debye-Scherrer, Guinier (Enraf Nonius, Huber)

• HZG4 theta-2theta goniometer
• Philips theta-2theta horizontal goniometer
• IRIS X-ray generator
• specimen spinners and graphite diffracted beam monochromators
• Cu, Co X-ray tubes
• attachment for reflectivity measurements ("knife") and texture-stress measurements

• theta-theta goniometer D500 (independent motion of the detector and the X-ray tube) Cu, Co, Mo, Cr X-ray tubes
• Position sensitive detector working both in the stationary mode (diffraction pattern can be recorded approximately over 10° in 2q) and in the continuous mode using a multi-channel analyzer with 8000 channels
• High temperature chamber with Be windows working up to 2500°C (the temperature control unit is controlled via PC)
• Measurements can be done alternatively under vacuum or a reaction atmosphere
• New Siemens generator

• theta-2theta vertical goniometer
• Philips PW 1140/90 X-ray generator
• Cu, Co, Mo, Cr X-ray tubes
• measurement and control system running on a PC

• HZG3 theta-2theta goniometer
• Philips PW 1830 X-ray generator
